Description
Fill-Rite 19 GPM, 115V AC 60 Hz High Flow Pump
This rugged, positive displacement, heavy pump is UL listed. Explosion proof UL listed 1/3 HP motor (115 VAC-60Hz) with sealed bearings, Heavy Duty switch, thermal overload protection and junction box. Carbon vanes and ceramic/carbon seal reduce wear and repair expense. Integral check valve with pressure relief on outlet side reduces pressure drop and improves vertical lift. Easy removable strainer, automatic bypass valve, 2 in. threaded bung for tank openings.
Features
UL/cUL LISTED
MADE IN USA
UP to 19 GPM
1/3 HP Motor
Diesel, Gasoline, Kerosene, E15, Biodiesel up to B20
2 Year Warranty
Iron rotor with carbon rotary vanes
Self priming
check valve, pressure relief valve and strainer included
Specifications
Acme Tools Brand Name
FILL-RITE
Acme Tools Part Number
FR711VA
Assembled Weight (lbs)
73
Brand / Model Compatibility
Diesel, Gasoline, Kerosene, E15, Biodiesel up to B20
Compatibility
Fill-Rite
Country of Origin
United States
Indoor / Outdoor
Indoor/Outdoor
Package Contents
700 series 20GPM fuel transfer pump, 3/4″ x 12′ Hose, 3/4″ Automatic Nozzle, Telescoping Suction Tube, 3/4″ x 90 degree elbow, wire nuts, ground wire, teflon tape, instruction manual, nozzle boot and hardware
Package Depth
22.25
Package Height
11.25
Package Weight
73
