Description
8 In. Single Bevel Compound Miter Saw
The 8-1/2-inch Single Bevel Sliding Compound Miter Saw from BOSCH is ideal for cutting joists and frames. It has a 12-Amp motor that runs the blade at a top speed of up to 5,600 rpm for faster cuts. This Bosch 8-1/2-inch single bevel compound miter saw weighs only 37 pounds and has a top handle so you can carry it around the job site with just one hand. Miter detents and positive stops make it easy to set the blade to the most commonly used angles. The Bosch sliding compound miter saw’s base extends up to 29 inches to make it easier to support longer beams. The trigger handle is designed for ambidextrous use and is ergonomic to reduce strain from extended operation.
Features
Bosch 8-1/2-inch single bevel compound miter saw comes with dust bag, wrench and blade
12-Amp motor achieves a top speed of 5,600 rpm
Weighs just 37 pounds for portability
Bosch compound miter saw has a handle for one-handed carrying
Detents and positive stops at 0, 15, 22.5, 31.6 and 45 degrees
Bosch sliding compound miter saw’s base extends up to 29 inches
Trigger handle is ergonomic and comfortable, and allows for ambidextrous use
1-year limited warranty
Specifications
Acme Tools Brand Name
BOSCH
Acme Tools Part Number
CM8S
Amperage (A)
12
Arbor Size (in)
0.625
Assembled Weight (lbs)
37.0
Base Construction
Aluminum
Beveling Capability
Single
Blade Material
Carbide
Blade Type
8-1/2 In. 48 Tooth Carbide Tipped Blade
Blade Wrench Included
Yes – Stored on Tool
Blades Included
1
California Proposition 65 Warning Required
No
Color / Finish
Blue, Silver
Cord Length (ft)
6
Cordless / Corded
Corded
Country of Origin
China
Diameter
8 1/2 in
Dust Collection
Yes
Dust Port
Yes
Electric Motor Brake
No
Electrical Cord Configuration
Heavy Duty
Electronic Speed Control
No
ETL Listed
No
External Motor Brush Access
No
Fence Size (HxL)
2-3/4 x 17-1/4
Fence Type
Sliding
Height (in)
18
Horsepower (hp)
Universal Motor
Integrated Laser Guide
No
Integrated Work Light
Not Featured
Internal Supplier Part #
0601B19110
Internet Product Code (IPC)
568613A4E1C
Keyless / Keyed Blade Change
Keyed
Length (in)
32
Manufacturer Warranty
Limited 1 Year
Miter Saw Type
Sliding Compound Miter
Motor Horsepower (hp)
0
Net Tool Weight (lbs)
37
Package Contents
Saw, (1) 48T Carbide Tipped Blade, Dust Bag, Blade Wrench
Package Weight
51.0
Package Weight (lbs)
51
Quick Release Vise
No
Saw Blade Diameter (in)
8½ in
Saw Drive
Direct Drive
Size
0.625 in
Spindle Lock
Yes
Tool-Less Blade Changing
No
UL Listed
Yes
Voltage
120 Volts
Width (in)
18
